Grinding Wheels, Type 27
Grinding wheels are used for dressing the surface of material, from hard and soft metals, to stone and concrete, to plastics. The various product designs and abrasive types allow a great range of uses.
- Additional information
- Description
- Specifications
- Data Sheets & Downloads
Additional information
| Size, Arbor, and Type | 4-1/2″ X 1/4″ X 5/8-11, A24R, 4 1/2″ X 1/4″ X 7/8, A24R, 4″ X 1/4″ X 5/8, ZA24T, 5″ X 1/8″ X 7/8, A24R Cutting Disc, 5″ X 1/4″ X 7/8, A24N, 6″ X 1/4″ X 7/8, WA24S, 7″ X 1/4″ X 5/8-11, A24R, 9″ X 1/4″ X 5/8-11, A24R, 4-1/2″ X 1/4″ X 7/8, A30N, 6″ X 1/4″ X 7/8, A24N, 4-1/2″ X 1/4″ X 5/8-11, G3 Ceramic, 4-1/2″ X 1/4″ X 7/8, G3 Ceramic, 4-1/2″ X 1/4″ X 7/8, Cotton, 4-1/2″ X 1/4″ X 7/8, ZA24T, 4-1/2″ X 1/4″ X 5/8-11, C24R Fast Cut, 4-1/2″ X 1/4″ X 7/8, C24R Fast Cut, 4″ X 1/4″ X 5/8, C24R Fast Cut, 7″ X 1/4″ X 5/8-11, C24R Fast Cut, 9″ X 1/4′ X 5/8-11, C24R Fast Cut |
|---|
Grinding wheels are used for dressing the surface of material, from hard and soft metals, to stone and concrete, to plastics. The various product designs and abrasive types allow a great range of uses.
See "Abrasive Materials and Applications" tab below for specific types and purposes.
Abrasive Materials and Applications
ZA24T - Zirconia Aluminum Oxide give consistent grinding action for quicker and easier working. The zirconia grain is sharper, cuts faster, and lasts longer than aluminum oxide grain.
T-grade bond and 24 grain size.
WA24S - White Aluminum Oxide with an S-grade bond is a contaminant-free design for fast cutting of stainless steel, ferrous metals, food grade, and nuclear applications. Contains virtually no iron, sulfur, or chlorine for rust-free and corrosion free results.
A24R - Aluminum Oxide Grain is the #1 selling 1/4" Depressed Center grinding wheel. The R-grade bond provides for longer life and excellent stock removal.
A24N Fast Cut - Aluminum oxide grain and soft N-grade bond provides for fast stock removal. This is an economical choice for metal and low-grade stainless steel.
A30N - Premium Aluminum oxide grain, with a soft N-grade bond, designed for use on aluminum, copper, zinc, and other soft metals.
C24R Fast Cut - Silicon carbide grain and R-grade bond are designed for easy working on masonry, concrete, and stone.
C3 Ceramic - CGW'S new ceramic grinding disc is the best choice for grinding stainless steel, titanium, Inconel, and other hard metals. Using CGW’s ceramic grinding disc will give a "cool grinding surface" since the grain has a self sharpening formula.
Cotton - Yes, Cotton. Cotton Fiber impregnated with aluminum oxide grains and latex bond for superior stainless steel and aluminum blending and finishing. Grind and finish with one wheel. Aluminum will not load up.
Safety Data Sheet (SDS), Vitrified Bond Abrasives
Safety Data Sheet (SDS), Resin Bonded Abrasives
Safety Data Sheet (SDS), Flap Disc Abrasives
